Low Cost 3000W Mini EDM Machine/Small Hole EDM Drilling Machine/Broken Tap Remover

FOB Reference Price:Get Latest Price
  • 1 - 1 Sets
    $2,380.00
  • 2 - 4 Sets
    $2,023.00
  • >=5 Sets
    $1,428.00
Report Suspicious Activity
Overview
Quick Details
Condition:
New
CNC or Not:
CNC
Drilling Speed:
1mm/min
Place of Origin:
Henan, China (Mainland)
Brand Name:
SFX
Model Number:
SFX-4000B
Voltage:
AC 220V/110V±10%
Power(W):
300~3000W
Dimension(L*W*H):
528*325*460
Weight:
26kg
Certification:
CE,ISO
Can Remove Broken Tools:
Tap, drill (carbide drill included), bolts, screw
Electrode Chuck Diameter:
2-13mm
Working Liquid:
Tap Water
Feature:
Auto feed; Depth setting, Alarm and auto retract
Power Frequency:
50Hz
Can Remove Taps Size(mm):
M2-M36
Max Processing Depth of Spindle Servo:
70mm
Adjustable Current:
Stepless Adjustment
Set Depth:
Alarm Automatically for Certain Depth
Power box size(mm):
420*220*370
After-sales Service Provided:
Overseas third-party support available
Supply Ability
Supply Ability:
300 Set/Sets per Month
Packaging & Delivery
Packaging Details
special carton packaging
Port
Beijing/Shanghai
Lead Time :
within 48 hrs after receiving the payment
Video Description

Portable EDM Tap Remover Global dealers recruitment announcement:

Just to be No.1

The details show



Specification for SFX-4000B:

Low Cost 3000W Mini EDM Machine/Small Hole EDM Drilling Machine/Broken Tap Remover

Technical Specification:



Item:

SFX-4000B

Input Voltage:

AC220V/110V±10%

Input Power(W):

300W~3000W

Electrode Chuck Diameter(mm):

2~13mm

Working Liquid:

Tap Water

Max Processing Depth of Spindle Servo(mm):

70mm

Max Processing Speed(mm/min):

2mm/min

Gross Weight:

28kg

Adjustable Current:

Stepless Adjustment

Set Depth:

Alarm Automatically for Certain Depth

Power box size(mm):

420*220*370

Packing Size(mm):

528*325*460



Quality Guarantee

Field Processing



Usage SkillsThe sche

Our Services

First of allour product will have to go through a thorough quality exam process to ensure that our devices won’t have any glitch before delivery.

Secondlythe warranty period is usually around one year and within this time frame, if there are any technical problems,we would repair them for free including the new parts that needed for the repair.

PSwe would offer free repair only when the damages are caused by technical deficiencies of the product itself, not man made errors, namely, the damages were done by mishandling the machine.

FAQ

1.Question: why our product is so cheap?

Answer: We have mass production to lower the cost, make interest to customers not pursuing high profit from one set of machine, but chasing large quantity to make profits. With the increase of sales, from 5 sets per time,50 sets per time,100 sets per time to now, our company produce thousands sets of main type machine, here comes the economic profit naturally.

2.Question: why our products’ quality are good?

Answer: Because of focus, so we are professional. We only make two kinds of machine.

1. The portable EDM machine with “remove broken taps as the main function”.
2. The hole machine whose processing object is “line cutting through the wire hole”. Our products are simple in category but easy for technology research,manufacture and organization. Which is suitable for the micro-small entrepreneur like us. Our company has always “take the light as the heavy”, and take “make good products to move the world” as our responsibility.

3.Question: why we promote sales on line?

Answer: our quality is stable, and we can receive money when we make the product customers receive with satisfaction! At the same time, we also hope to develop the cheapest way of sales, and to make earning to customers!

4.Question: Why sometimes we would refuse customers’ purchasing request?

Answer: Some clients knows little of the function of our machine, we will offer a more proper processing solve solution with patience to avoid the mis-choice which would cost waste. After the clearly telling of us to customers honestly, although we lost a sale, the thanks which customers say to us make we pleased. “Rose to others, smell in hands”.
