Low Cost 3000W Mini EDM Machine/Small Hole EDM Drilling Machine/Broken Tap Remover
- Condition:
-
New
- CNC or Not:
-
CNC
- Drilling Speed:
-
1mm/min
- Place of Origin:
-
Henan, China (Mainland)
- Brand Name:
-
SFX
- Model Number:
-
SFX-4000B
- Voltage:
-
AC 220V/110V±10%
- Power(W):
-
300~3000W
- Dimension(L*W*H):
-
528*325*460
- Weight:
-
26kg
- Certification:
-
CE,ISO
- Can Remove Broken Tools:
-
Tap, drill (carbide drill included), bolts, screw
- Electrode Chuck Diameter:
-
2-13mm
- Working Liquid:
-
Tap Water
- Feature:
-
Auto feed; Depth setting, Alarm and auto retract
- Power Frequency:
-
50Hz
- Can Remove Taps Size(mm):
-
M2-M36
- Max Processing Depth of Spindle Servo:
-
70mm
- Adjustable Current:
-
Stepless Adjustment
- Set Depth:
-
Alarm Automatically for Certain Depth
- Power box size(mm):
-
420*220*370
- After-sales Service Provided:
-
Overseas third-party support available
- Supply Ability:
- 300 Set/Sets per Month
- Packaging Details
- special carton packaging
- Port
- Beijing/Shanghai
- Lead Time :
- within 48 hrs after receiving the payment
Portable EDM Tap Remover Global dealers recruitment announcement:
Specification for SFX-4000B:
Low Cost 3000W Mini EDM Machine/Small Hole EDM Drilling Machine/Broken Tap Remover
Technical Specification:
Item: | SFX-4000B |
Input Voltage: | AC220V/110V±10% |
Input Power(W): | 300W~3000W |
Electrode Chuck Diameter(mm): | 2~13mm |
Working Liquid: | Tap Water |
Max Processing Depth of Spindle Servo(mm): | 70mm |
Max Processing Speed(mm/min): | ≈2mm/min |
Gross Weight: | 28kg |
Adjustable Current: | Stepless Adjustment |
Set Depth: | Alarm Automatically for Certain Depth |
Power box size(mm): | 420*220*370 |
Packing Size(mm): | 528*325*460 |

First of all, our product will have to go through a thorough quality exam process to ensure that our devices won’t have any glitch before delivery.
Secondly, the warranty period is usually around one year and within this time frame, if there are any technical problems,we would repair them for free including the new parts that needed for the repair.
PS: we would offer free repair only when the damages are caused by technical deficiencies of the product itself, not man made errors, namely, the damages were done by mishandling the machine.
1.Question: why our product is so cheap?
Answer: We have mass production to lower the cost, make interest to customers not pursuing high profit from one set of machine, but chasing large quantity to make profits. With the increase of sales, from 5 sets per time,50 sets per time,100 sets per time to now, our company produce thousands sets of main type machine, here comes the economic profit naturally.
2.Question: why our products’ quality are good?
Answer: Because of focus, so we are professional. We only make two kinds of machine.
1. The portable EDM machine with “remove broken taps as the main function”.
2. The hole machine whose processing object is “line cutting through the wire hole”. Our products are simple in category but easy for technology research,manufacture and organization. Which is suitable for the micro-small entrepreneur like us. Our company has always “take the light as the heavy”, and take “make good products to move the world” as our responsibility.
3.Question: why we promote sales on line?
Answer: our quality is stable, and we can receive money when we make the product customers receive with satisfaction! At the same time, we also hope to develop the cheapest way of sales, and to make earning to customers!
4.Question: Why sometimes we would refuse customers’ purchasing request?
Answer: Some clients knows little of the function of our machine, we will offer a more proper processing solve solution with patience to avoid the mis-choice which would cost waste. After the clearly telling of us to customers honestly, although we lost a sale, the thanks which customers say to us make we pleased. “Rose to others, smell in hands”.
